Life Source Oxygen Concentrator 5L

Lifesource Oxygen Concentrator LS-7F-5B with Nebulizer & Purity Meter

The Lifesource LS-7F-5B Oxygen Concentrator is designed for safe and reliable home oxygen therapy. It electronically separates oxygen from room air and delivers high-purity oxygen directly to the user through a nasal cannula. Clinical studies confirm oxygen concentrators are therapeutically equivalent to other oxygen delivery systems.

Key Features

• Complete plastic outer shell for enhanced safety and durability
• Built-in nebulizer and oxygen purity meter
• Timing accumulation function displays total working hours
• Timer shut-off function for user convenience
• Low oxygen concentration alarm
• Power failure, pressure, cycle failure & compressor failure alarms
• Pressure relief safety valve for added protection
• Compressor overheating protection ensures long service life
• Integrated storage box for accessories like nasal cannula and manual
• Designed for continuous operation

Performance Specifications

• Oxygen Purity: 93% ±3%
• Oxygen Concentration Range: 87% – 95.5%
• Flow Rate: 1–5 L/min
• Output Pressure: 40–70 kPa
• Maximum Outlet Pressure: 20–50 kPa (2.9–7.25 psi)
• Pressure Relief Activation: 250 kPa ±25 kPa
• Sound Level: ≤59 dB(A)
• Minimum Operating Time: 30 minutes

Electrical & Physical Details

• Power Supply: 220V ±22V, 50Hz ±1Hz
• Input Power: ≤700 VA
• Electric Classification: Class II, Type B applied part
• Weight: 27 kg (60 lbs)
• Dimensions: H 55.6 × W 28.5 × D 47 cm
• Operating Conditions
• Operating Temperature: 10°C – 35°C (50°F – 95°F)
• Relative Humidity: 20% – 60%
• Atmospheric Pressure: 86–106 kPa
• Altitude:

Up to 1828 m (6000 ft): No performance degradation

1828–4000 m: Efficiency below 87%

Safety Notice

• Keep away from flammable and explosive gases
• Intended for individual home use
